Type
Ducati V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liqued cooled
Displacement
1,158 cc (71 cu in)
Bore and stroke
83 x 53.3 mm
Compression Ratio
14:1
Power
125 kW (170 hp) @ 10,500 rpm
Torque
125 Nm (12,7 kgm) @ 8,750 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 46mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel muffler, double catalytic converter and 4 lambda probes
Gearbox
6 speed with Ducati Quick Shift up/down
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z16; Rear sprocket Z42
Clutch
Multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Ø 50 mm fully adjustable USD fork, electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front wheel
Light alloy cast, 3" x 19"
Front tyre
Pirelli Scorpion Trail II 120/70 ZR 19
Real suspension
Fully adjustable monoshock, electronic adjustment with Ducati Skyhook Suspension, aluminium double-sided swingarm
Rear wheel
Light alloy cast, 4.5" x 17"
Rear tyre
Pirelli Scorpion Trail II 170/60 ZR 17
Wheel travel
170 mm / 180 mm (6.7 in / 7.1 in)
Front brake
2 x Ø 330 mm semi-floating discs, radially mounted Brembo M50 Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
6.5" TFT colour display with Ducati Connect and full-map navigation system
Wet weight
235 kg (no fuel)
Seat height
Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in) 855 mm - 875 mm (33.7 in - 34.4 in) with high seat accessory 810 mm - 830 mm (31.9 in - 32.7 in) with low seat accessory 790 mm - 810 mm (31.1 in - 31.9 in) with low seat + low suspension kit accessory
Wheelbase
1,566 mm (61.7 in)
Rake
24.2°
Trail
100.6 mm (4.0 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Vehicle Hold Control, Radar system (ACC + BSD)
Standard equipment
Ducati Skyhook Suspension, Minimum preload, Ducati Quick Shift, Cruise control, Hands-free, Backlit handlebar switches, 6.5" TFT colour display with Ducati Connect and full-map navigation system, Full LED headlight, Tyre pressure monitoring system (TPMS), Hands-free fuel tank cap, Auxiliary LED lights, Heated rider seat, Heated passenger seat, Heated handgrips, Central stand, Plastic side panniers
Warranty
48 months, unlimited mileage
Valve clearance check
60,000 km (36,000 miles)
Standard
Euro 5
Co emissions
162 g/km
Consumption
7.0 l/100km
