Type
Ducati V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
Displacement
1,158 cc (71 cu in)
Bore and stroke
83 mm x 53.5 mm
Compression Ratio
14:1
Power
170 hp (125 kW) @ 10,750 rpm
Torque
124 Nm (12,6 kgm) @ 9,000 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 46mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel muffler, double catalytic converter and 6 lambda probes
Gearbox
6 speed with Ducati Quick Shift up/down
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=36/20, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z16; Rear sprocket Z42
Clutch
Multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Öhlins Ø 48 mm fully adjustable usd fork with TiN treatment, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
Front wheel
Marchesini light alloy forged, 3.5" x 17"
Front tyre
Pirelli Diablo Rosso IV 120/70 ZR17
Real suspension
Öhlins TTX36 fully adjustable monoshock, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode, electronic preload adjustment, aluminium single-sided swingarm
Rear wheel
Marchesini light alloy forged, 6" x 17"
Rear tyre
Pirelli Diablo Rosso IV 190/55 ZR17
Wheel travel
170 mm / 170 mm (6.7 in / 6.7 in)
Front brake
2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 280 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
6.5" TFT colour display with Ducati Connect and full-map navigation system
Wet weight
227 kg (no fuel)
Seat height
Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in) 870 mm - 890 mm (34.3 in - 35.0 in) with high foam seat accessory 855 mm - 875 mm (33.7 in - 34.4 in) with mid/high foam seat accessory 810 mm - 830 mm (31.9 in - 32.7 in) with low foam seat accessory
Wheelbase
1,595 mm (62.8 in)
Rake
25,75°
Trail
120 mm (4.7 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Vehicle Hold Control, Radar system
Standard equipment
Öhlins Smart EC 2.0 electronic suspension, Ducati Quick Shift, Adaptive Cruise Control, Hands-Free, Backlit handlebar switches, Backlit handlebar switches, 6.5" TFT colour display with Ducati Connect and full-map navigation system, Full LED headlight, Carbon fibre front mudguard and beak, Type- approved Akrapovic muffler
Warranty
48 months, unlimited mileage
Valve clearance check desmo
15,000 km (9,000 miles) / 24 months
Valve clearance check
60,000 km (36,000 miles)
Standard
Euro 5+
Co emissions
152 g/km
Consumption
6,6 l/100km
Notes
Only for countries where Euro 5 standard applies.
