Type
Ducati V4 Desmosedici stradale, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
Displacement
1,103 cc (67 cu in)
Bore and stroke
81 x 53.5 mm
Compression Ratio
14:1
Power
132 kW (180 hp) @ 12,250 rpm
Torque
118 Nm (12.0 kgm) @ 9,500 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 50mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel pre-silencer, double catalytic converter and 6 lambda probes. EU 5+ compliant. Akrapovic titanium muffler
Gearbox
6 speed with Ducati Quick Shift up/down
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z15; Rear sprocket Z43
Clutch
Multiplate dry clutch with slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Öhlins Ø 48 mm fully adjustable usd fork with TiN treatment, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
Front wheel
Marchesini light alloy forged, 3.5" x 17"
Front tyre
Pirelli Diablo Rosso IV Corsa 120/70 ZR17
Real suspension
Öhlins TTX36 fully adjustable monoshock, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode, electronic preload adjustment, aluminium single-sided swingarm
Rear wheel
Marchesini light alloy forged, 6" x 17"
Rear tyre
Pirelli Diablo Rosso IV Corsa 190/55 ZR17
Wheel travel
170 mm / 170 mm (6.7 in / 6.7 in)
Front brake
2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
6.5" TFT colour display with Ducati Connect and full-map navigation system
Wet weight
225 kg (no fuel)
Seat height
Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in) 810 mm - 830 mm (31.9 in - 32.7 in) with low seat accessory
Wheelbase
1,592 mm (62.7 in)
Rake
25,75°
Trail
120 mm (4.7 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Mode, Power Mode, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Vehicle Hold Control, Radar system (Adaptive Cruise Control + Blind Spot Detection)
Standard equipment
Öhlins Smart EC 2.0 electronic suspension, Ducati Quick Shift, Hands-free, Backlit handlebar switches, 6.5" TFT colour display with Ducati Connect and full-map navigation system, Full LED headlight, Carbon fibre front mudguard and beak, Carbon fibre handguards, Type-approved Akrapovic muffler
Warranty
48 months, unlimited mileage
Valve clearance check
30,000 km (18,000 miles)
Standard
Euro 5+
Co emissions
170 g/km
Consumption
7.3 l/100km
