Type
Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled
Displacement
890 cc
Bore and stroke
96 x 61.5 mm
Compression Ratio
13.1:1
Power
88 kW (120 hp) @ 10,750 rpm
Torque
93.3 Nm (69 lb-ft) @ 8,250 rpm
Fuel injection
Electronic fuel injection system. One injector per cylinder. Full ride-by-wire.
Exhaust system
2-1-2 system, with 1 catalytic converters and 3 lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down 2.0
Primary drive
Straight cut gears; Ratio 1.84:1
Ratios
1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25
Final drive
Chain 520; Front sprocket 15; Rear sprocket 42
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch.
Frame
Monocoque Aluminium
Front suspension
Öhlins NIX30 43 mm with TiN treatment, fully adjustable usd fork
Front wheel
Y-shape, 6-spokes light alloy, 3.50" x 17"
Front tyre
Pirelli Diablo Rosso IV 120/70 ZR17
Real suspension
Fully adjustable Öhlins monoshock. Aluminium double-sided swingarm
Rear wheel
Y-shape, 6-spokes light alloy, 5,50” x 17”
Rear tyre
Pirelli Diablo Rosso IV 190/55 ZR17
Wheel travel
120 mm - 150 mm
Front brake
2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M50 piston calipers with Bosch Cornering ABS.
Rear brake
245 mm disc, 2-piston caliper with Bosch Cornering ABS
Instrumentation
Digital unit with 5" TFT colour display, 800 x 480 px resolution
Wet weight
176 kg (388 lb) (no fuel)
Seat height
837 mm (33 in)
Wheelbase
1,465 mm (57.7 in)
Rake
23.6°
Trail
93 mm (3.7 in)
Fuel tank capacity
15 l - 4 gallon (US)
Number seats
Single seat Two seats, if passenger seat kit accessory is mounted
Safety equipment
Riding Modes, Power Modes, Bosch Cornering ABS, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Auto tyre calibration, Ducati Brake Light (DBL)
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Full LED headlights with Daytime Running Light (DRL), Auto-off indicators, Lithium-ion battery, Ducati Power Launch (DPL), Pit Limiter, Coming Home, Single seat configuration
Ready for
Lap Timer Pro, Anti-Theft, Cruise Control, Tyre Pressure Monitoring System (TPMS), USB port, Ducati Multimedia System (DMS), "Turn By Turn" navigator, Heated Grips
Warranty
24 months unlimited mileage
Valve clearance check desmo
15,000 km (9,000 mi) / 24 months
Valve clearance check
30,000 km (18,000 mi)
Standard
Euro 5+
Co emissions
123 g/km
Consumption
5,3 l/100km
