Type
Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled
Displacement
890 cc (54.3 cu in)
Bore and stroke
96 mm x 61.5 mm (3.8 in x 2.4 in)
Compression Ratio
13.1:1
Power
110.3 hp (81.1 kW) @ 9,000 rpm
Torque
92 Nm (9.4 kgm, 68 lb ft) @ 7,000 rpm
Fuel injection
Electronic fuel injection system, Ø 52 mm throttle body with Ride-by-wire
Exhaust system
Stainless steel muffler, single catalytic converter and lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down 2.0
Primary drive
Straight cut gears; Ratio 1.84:1
Ratios
1=13/38 2=17/35 3=20/32 4=22/29 5=24/27 6=26/25
Final drive
Chain 520; Front sprocket Z=15; Rear sprocket Z=46
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch.
Frame
Monocoque Aluminium
Front suspension
KYB 46 mm upside-down fork, fully adjustable
Front wheel
Cross-spoked, tubeless, 2.15’’x21’’
Front tyre
Pirelli Scorpion Rally STR 90/90 - 21 M/C 54V M+S TL (A)
Real suspension
KYB shock absorber, fully adjustable, remote preload adjustment, full floater progressive link
Rear wheel
Cross-spoked, tubeless, 4.5’’x18’’
Rear tyre
Pirelli Scorpion Rally STR 150/70 R18 M/C 70V M+S TL
Wheel travel
230 mm / 220 mm (9.1 in / 8.7 in)
Front brake
2 x Ø 305 mm semi-floating discs, radially mounted Brembo monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
Digital unit with 5" TFT colour Display, 800 x 480 px Resolution
Wet weight
209 kg (461 lb)
Seat height
880 mm (34.6 in) 900 mm (35.4 in) with high seat 860 mm (33.9 in) with low seat 840 mm (33.1 in) with low seat and low suspension kit
Wheelbase
1,615 mm (63.6 in)
Rake
27°
Trail
114 mm (4.5 in)
Fuel tank capacity
18 l (4.8 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Bosch Cornering ABS, Ducati Brake Light (DBL) EVO
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Lithium-ion battery, Quick adjustment buttons, Coming Home, Cruise control, TFT colour display, Full LED lighting system, Daytime Running Light (DRL), Dynamic turn indicators, Self cancelling turn indicators, Two USB ports
Ready for
Anti-Theft, Additional LED lights, Tyre Pressure Monitoring System (TPMS), Ducati Multimedia System (DMS), Heated grips, Turn-by-Turn navigation system
Warranty
48 months, unlimited mileage
Valve clearance check
45,000 km (28,000 mi)
Standard
Euro 5+
Co emissions
125 g/km
Consumption
5.4 l/100 km
